• 代替できる部品品番: パソコン用電源 ENP-2320 充電池種類: GSBB0C 出力電圧: +3.3V 17A, +5V 13A, +12V 16A, 入力電圧: 100-240V 4-2A VAC Auto Sen 商品番号: SHU17665_Se 互換 250W ATX Enhance ENP-2320A Power Supply 互換品番:

    Output Wattage 250W
    This is an 80 PLUS Bronze Certified: Power Supply Units (PSUs) that have more than 80% energy efficiency at 20%, 50% and 100% of rated load, and a power factor of 0.9 or greater at 100% load. That is, PSUs that waste 20% or less electric energy as heat at the specified load levels, thus reducing electricity use and bills compared to less efficient PSUs.

    Dimension: 3.2"(W) X 5.9"(L) X 1.7"(H)
    Form Factor: TFX12V
    Active PFC/CE, UL/CUL Safety Compliant
    Input Voltage: 100-240V 4-2A VAC Auto Sensing
    Frequency: 60-50Hz
    Holdup Time: > 14ms @ Full Load
    MTBF: 100,000 HRS
    DC Output: +3.3V 17A, +5V 13A, +12V 16A, -12V 0.3A, +5Vsb 2A
    Dimensions: 5.9"x 3.2"x 1.7" (150Lx82Wx43H mm)
    1x 20/24 Pin ATX Connector
    1x 4-Pin 12V
    3x Peripheral Connectors (MOLEX 4 PIN)
    1x Power Connector for Floppy Drives.
    2x SATA connectors

    Replacement/Compatibility Reference:

    Achme AM630BS20S
    Shuttle PS-X200W
    WIN-200PS (original PS has extra 6 pin auxiliary connector)
    Enhance ENP-2320
    Enhance ENP-2320A
    Enhance ENP-2322B-G
    Enhance ENP-2322C
    Enhance ENP-0812A

    Use this power supply to replace the power in your Shuttle XPC mini-barebones system such as SB61G2, SS51G, SK41G SB51G and many others.
    NOTE: If you own the early Shuttle SV25 with the wires coming out the top (long side) of the power supply, this model will not fit in your case.

    対応ラッ モデル: SOLTEK EQ2000 - 200W PFC
    SOLTEK EQ3701M - 200W PFC
    Shuttle XPC SB51G/SB51GB - 200W PFC
    Shuttle XPC SB52G2 - 200W
    Shuttle XPC SB61G2 - 200W PFC
    Shuttle XPC SS51G/SS51G1(v2.0) - 200W PFC
    Shuttle XPC SS50C - 160W/150W PFC
    Shuttle XPC SV24/SV25/FV25 - 150W
    Shuttle XPC SN45G - 200W PFC up to 190mm
    Shuttle XPC SK41G - 200W PFC
    Shuttle XPC SN41G2 - 200W PFC
    Shuttle XPC SN41G2B - 200 PFC
    Shuttle XPC SS40G - 200W PFC
    Shuttle XPC SK41G - 200W PFC
